SED-8000 大功率交流转直流数显电源
WEHO SED-8000W 是一款专为尖端工业与科研领域设计的超大功率开关电源,其单组输出功率高达惊人的 8000W。该型号是驱动大功率直流电机、电动汽车充电桩核心模块、工业等离子设备、大功率老化测试平台以及其他需要巨量直流能源供应的重型设备的理想选择,为极限工况提供稳定可靠的动力源泉。
该系列电源具备强大的性能和高度的灵活性,支持 180-264VAC 宽范围交流输入,并提供从 12V/300A 到 220V/33A 等多种直流输出规格。高达 91% 的转换效率和先进的强制风冷散热系统,确保了其在-20°C至+60°C的宽温环境下依然能持续满载运行。尤为突出的是,SED-8000W 提供了可定制化的外部控制功能,用户可通过旋钮直接调节电压与电流,并支持远程开关控制,为精确操作和系统集成提供了极大便利。
在安全与可靠性方面,SED-8000W 内置了完善的短路、过载、过压及过温保护功能,全方位保障设备安全。其坚固的工业级设计,使其能够从容应对严苛的挑战,是一款集超凡功率、高效性能与精密可调于一体的旗舰级工业电源解决方案。
- 说明
型号model | SED-8000-12 | SED-8000-24 | SED-8000-36 | SED-8000-48 | SED-8000-72 | SED-8000-96 | SED-8000-110 | SED-8000-150 | SED-8000-220 |
直流输出电压 Dc output voltage |
12V | 24V | 36V | 48V | 72V | 96V | 110V | 150V | 220V |
额定电流 Rated current |
300A | 200A | 150A | 120A | 100A | 75A | 65.5A | 48A | 33A |
电流范围 Current range |
0-300A | 0-200A | 0-150A | 0-120A | 0-100A | 0-75A | 0-65.5A | 0-48A | 0-33A |
额定功率 Rated Power |
8000W | ||||||||
纹波 Ripple |
380mV | 450mV | 500mV | 500mV | 500mV | 600mV | 850mV | 900m | 1000m |
恒流范围 Constant current range |
6-12V | 12-24V | 18-36V | 24-48V | 36-72V | 48-96V | 55-110V | 75-150V | 110-220V |
电压精度 Voltage accuracy |
±1.0% | ||||||||
线路调整率 Line Regulation |
±1.0% | ||||||||
负载调整率 Load Regulation |
±1.0% | ||||||||
启动与上升时间 Startup&Rise Time |
1500mS,100mS/230VAC(满载)(Fully loaded) | ||||||||
电压范围 Voltage range |
180-264VAC/245-370VDC | ||||||||
频率范围 Frequencyrange |
45Hz-65Hz | ||||||||
功率因数 Power Factor |
PF≥0.65/230VAC(满载)(Fully loaded) | ||||||||
效率 Efficiency |
86% | 87% | 89% | 90% | 90% | 90% | 90% | 91% | 91% |
交流电流 ACCurrent |
<55A | ||||||||
漏电流 Leakage Current |
<3.0mA/240VAC | ||||||||
短路保护 Short Circuit |
恒定电流Enter constant current | ||||||||
过温保护 Over temperature |
关闭输出,并在温度下降后自动恢复或重启Shut down the output,and automatically recover or restart after the temperature drops | ||||||||
输出电压 Output voltage |
0-26.4V | 0-39.6V | 0-52.8V | 0-66V | 0-79.2V | 0-105.6V | 0-121V | 0-165V | 0-242V |
输出恒流 Output constant current |
0-300A | 0-200A | 0-150A | 0-120A | 0-100A | 0-72A | 0-65.5A | 0-48A | 0-33A |
外部电位器 Extemal potentiometer |
外部电位器控制(电压、电流)(可定制)External potentiometer control (voltage,current)(customizable) | ||||||||
电压和电流可调 Voltage and current adjustable |
通过旋钮调节Adjust by knob | ||||||||
模拟电压控制 Analog voltage control |
电压和电流可定制Voltage and current can be customized | ||||||||
远程控制开关 Remote control switch |
默认电源开启,高电平电源关闭(3V-12V)(可定制)Default power on,high level power off(3V-12V)(customizable) | ||||||||
工作温度 Operating temperature |
-20-+60℃ | ||||||||
工作湿度 Operating humidity |
-20-90%RH无冷凝-20-90%RH without condensation | ||||||||
存储温度/湿度 Storage temperature/humidity |
-40-+85℃,10-95%RH无冷凝without condensation | ||||||||
抗振动能力 Vibration resistance |
10-500Hz 2G加速度,每周期10分钟, X、Y、Z轴各60分钟。10-500Hz,2G10 minutes/cycle,60 minutes for each ofX,Y and Z axes | ||||||||
绝缘电阻 Insulation resistance |
Input tooutput:100Mhms/500VDC/25℃/70%RH | ||||||||
耐压强度 Pressure resistance |
I/P-O/P:1.2KVAC I/P-FG:1.2KVACO/P-FG:0.5KVAC | ||||||||
尺寸 Dimension |
351×210.8×148.5mm | ||||||||
重量 Weight |
8.5kg | ||||||||
